Specification
1. Working table design as 8mm in thickness 5052 aluminum alloy
materials,no deformation when heating and have longer service time.
2. The vacuum pump performance could match the Europe brand,and its
main parameter have over the Germany products .the pump head adopts
low alloy cast iron ,higher abrasion resistance and corrosion
resistance.
3. The machine frame board all choose whole steel plate which made
up 8 piece in one part,the heating could be spread all-around
workpiece when the machine working,keep the welding complete..
4. Electric parts:low voltage appliances adopts Schneider
brand,inverter choose Siemens. Omron time relay,AirTAC pneumatic
parts ,long service time.
5. when the machine make complete membrane,silicone board only play
the role of warm.positive pressure working without silicone board
but small piece membrane.
6. The machine have heat and cold system to work ,cold air in after
finishing the membrane out.no rebound and good quality.
7. Advanced pneumatic ball valve for accuracy of execute system.
8. White steel sensor for stable performance and service life.
9. Heating board adopts 35mm in thickness aluminum board which have
good thermal conductivity,fast heating speed and will be save more
than 10% electricity.
Technical support
1. By phone, email,skype around the clock
2. Engineer available to service machinery overseas
3. We could the video and pictures to teach our client how to use
the machine
After sales services
Normal machine is properly adjusted before dispatch
You will be able to use the machine very soon
You will be able to get free training adivce towards our machine in
our factory
You will get free suggestion consulting technical support and
service by email tel and lifetime technical support.
| Model | R-2480 |
| Covering Material | PVC |
| Interior Worktable Size(mm) | 2500×1300 |
| Overall dimension | 5500x1500x1400mm |
| Vacuum tank volume | 2.5meter |
| Vacuum pump | 1.8kw |
| Maximum base material processing thickness | <=1mm |
| PVC Max. processing thickness(mm) | 0.5mm |
| Working Pressure(Mpa) | ≥-0.01 |
| Total Power (kw) | 20 |
| Actual power | About 8kw |
| Weight(kg) | 2000 |
| Working tables number | 2 |
| Table moving mode | Full-automatic |
Price (FOB Qingdao) | 4050USD |
| Remark | RHINO CNC |
