Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking

    Buy cheap Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking from wholesalers

    Buy cheap Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking from wholesalers
    • Buy cheap Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking from wholesalers
    • Buy cheap Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking from wholesalers
    • Buy cheap Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking from wholesalers

    Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking

    Ask Lasest Price
    Brand Name : Rhino
    Model Number : RSKM25-H
    Certification : CE/ISO/FDA
    Price : 2000-20000usd/set
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 1000 sets per month
    Delivery Time : 10-14 working days
    • Product Details
    • Company Profile

    Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking

    European market ATC CNC Router automatic tool changer 20 pieces for woodworking


    Feathers


    1. PE strong cover of spindle to keep environment more clean

    2. Limit switch for Taiwan Jiazun, Germany Biduk;

    3. The pneumatic parts and the filter system are all guaranteed to be authentic products of the original Taiwanese Yadeke.

    4. Automatic tool changer handle, standard configuration of Taiwan BT30 and ISO30, maximum clamp up to 20MM, special tool diameter can be customized spindle, but also can choose Italian original tool handle.

    5. Inverter system standard configuration Shenzhen Sifang,

    High-performance domestic mainstream products, compared with other domestic brand manufacturers stable performance, long service life, and can choose Taiwan Taida Inverter (standard processing center model)

    6. Control system Syntec 6MB from taiwan stable and easy to operate

    Also we have more economic control system NK60A for your option

    7. Have a completely clean and adsorb dust system,automatic dust tank with stronger suction better than other ATC cnc machines


    Application


    1. Wood furniture industry: Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

    2. Advertising industry: Advertising identification, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.

    3. Die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, wooden planjs and other non-metallic mold.

    4. Relief sculpture and 3D engraving.

    5. Cylindrical object.

    6. Office and home fruniture made by MDF

    ATC CNC Router working samples


    Description & Specifications:

    X Working Area2000mm
    Y Working Area4000mm
    Z Working Area200mm/300mm/600mm
    Table size1300x2500mm
    Traveling Positioning Accuracy±0.02mm
    Repositioning Positioning Accuracy±0.02mm
    Table SurfaceBy vacuum
    X,Y ,Z StructureXY gear wheel, Z ball screw
    Max. Rapid Travel Rate90000mm/min
    Max. Working Speed30000mm/min
    SpindleItaly 9.0Kw HSD/HQD ATC spindle
    Spindle Speed0-18000r/min
    MotorYaskawa Japan Servo Motor
    DriverYaskawa Japan Servo Motor
    CommandG-code*.u00*.mmg*.plt
    Working voltageAC 220V/380V
    Control SystemTAIWAN Syntec Control System
    Guide rail30 Square rail (TAIWAN TBI/HIWIN )
    N.W./G.W.2000KGS
    Accessories (for free)

    1 Tool Box 1

    2 Woodworking Knife

    All type 12 Different size

    3 collet 3.17, 4, 6, 12.7 4

    4 Allen wrench M6 1

    5 Open-end wrench 27-30 45-52 2

    6 Certificate, CE

    7 Adjustment screw 4

    8 Clamps 8

    9 Spanner, 3,4,5,6mm, 4

    10 Fuse core 2

    12 Software CD 1


    RSKM25-H details

    Whole structure heavy duty make sure working more stable and higher precision


    Original Italy HSD 9KW ATC spindle with rpm 0-18000 good quality 0 complain


    Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking

    Vacuum table 12 zones with T-SLOT combination more easier to operate


    Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking

    Good quality disc tool changer 12 pieces with ISO 30 chuck not easy to broken12pieces together with machine when delivery


    Efficient ATC CNC Router Machines , 20pcs Auto Tool Changer CNC Routers For Woodworking

    Also we have linear tool changer for your option
